Specs for 2027 Jayco - Eagle
Floorplan: 312BHOK (Travel Trailer)

General

Dimensions

Weights

2027 Jayco Eagle RVs for Sale Near You

Capacities

Exterior

Electrical

Features

Exterior Equipment:
5 in. Freshwater drain valve
5 in. Magnum Truss™ roof w/ Plywood Roof Decking
Alpha Ply TPO Roof membrane (thickest membrane w/ Limited Lifetime Warranty)
50-amp detachable power cord
Motion activated LED lighting in pass through area(s)
Auto-grade vinyl graphics
Automotive style front cap with max turn radius (painted on select models)
Black tank flush
LED Light & Termination w/ "No Surprise" additional T-Valve
Climate Shield™ zero-degree tested weather protection:
Fully enclosed and heated underbelly (ducted)
35,000 BTU furnace
Double layer fiberglass batt insulation in ceiling and floor
Double sided radiant barrier insulation (roof, floor and behind cap)
100% Residential plumbing throughout
Dual 20 lb. LP bottles
Factory installed roof ladder (SLE's prepped)
Galvanized steel coated outside kitchens
HELIX Cooling System™ (industry exclusive):
Jayco exclusive insulated dual duct design
Directional and closeable A/C vents
Larger return air vents with user accessible filters
Independent satellite and cable hookups (outside kitchens and/or pass through storage areas)
LED exterior lighting package
LP quick connect for gas griddle
Metal slam latch baggage doors
Nautilus 2.5 water connections
Nitrogen filled undermount spare tire (model/option varies 15 in. or 16 in.)
Quick connect water connections (door side hot/cold and off door side cold only)
Stronghold VBL™ walls (laminated sidewalls, rear walls and slide out walls)
"Brianza" high gloss fiberglass sidewalls
Star Link Prep
Rear Camera Prep

Interior Equipment:
2-piece high gloss bathroom surround
Teak Seat Shower Prep
5/8 in. tongue-and-groove plywood flooring
75 lb. full extension drawer guides
Magnetic Catches on all doors & drawers throughout
30 in. X 22 in. Shower Skylight w/ built in LED light
Bedroom TV, SAT, CABLE prep
P.A.P. prepped bedroom (both sides)
Extra 120V power outlets in kitchen and slide rooms (where applicable)
Gas strutted under bed storage
High Sheen handcrafted door/drawer fronts
Medicine cabinet with custom framed mirror
Black glass 11 cu. ft. 12V refrigerator
kitchen faucet with pull-out sprayer
Porcelain foot flush toilet with soft closed lid
Residential vinyl flooring throughout (NO CARPET)
Theater seating (select models)
Tri-fold hide-a-bed sofa with residential memory foam sleep surface (select models)
USB/USB-C 12V charging ports (multiple locations throughout)
Water Shutoff at all faucet locations
100% No Floor Heat Vents
4 in. Interior Ceiling Can Lighting (4000K lumen)
Venting windows throughout

Customer Value Package:
15K BTU "Whisper Quiet" A/C and bedroom A/C prep
4K Ultra LED HD Smart TV in living room (varies from 40" to 65")
50-amp service with fully ducted A/C System
60K on-demand tankless water heater
Custom machined aluminum rims
Electric patio awning
Hidden hinges soft close cabinet doors
Interior "MB Quart Entertainment" w/ MB Quart Sound (TV & Phone)
Keyed-Alike™ lock system
MORryde StepAbove® entry steps (main entrance) with blue LED light
Rain proof bathroom power vent
Rear 2 in. towing receiver
Winegard Air 360 Antenna
Overlander I Solar Package (200W panel and 30-amp solar controller)
Inverter pre-wire (multiple locations throughout)

Luxury Package:
Residential stringless night shades throughout
Retractable Shower curtain w/ mold resistant material
Dove Tail Drawers throughout
Soft closed cabinet doors (upper & lower) throughout
NuvoH2O citrus-based water filtration & softening treatment system (Extends the life of your water heater, plumbing fixtures, and appliances)
LED fireplace with 5,000 BTU electric space heater (select models)
"Camp Mode" & "Storage Mode" Power Disconnect
Washer/Dryer Prep (Select models)
Solid Surface Kitchen Countertop(s)
(2) Ceiling Light dimmer switches
Copper-infused 8 in. thick mattress with temperature regulating material
Custom Padded Headboard with Cellphone & Tablet holder (bed slides only)
Residential 66 in. x 80 in. Olympic Mattress with under-bed storage

4 Star Handling Package:
Dexter Axles with NEV-R-Adjust® brakes and E-Z Lube® hubs
15 in. Rainier E-Rated tires OR 16 in. Rainier H-Rated tires
MORryde CRE-3000™ rubberized suspension
Wet bolt fasteners with bronze bushings
