2024 Keystone Passport SL Series East 229RK

MSRP

$44,752

MSRP + Destination

$44,752

Currency

US Dollars

Basic Warranty

12 Months

Structure Warranty

36 Months

Length (ft)

27.25

Length (in)

327

Length (ft/ft)

27

Length (ft/in)

3

Length (m)

8.3

Length (mm)

8300

Height (in)

128

Height (mm)

3251.2

Dry Weight (lbs)

5227

Dry Weight (kg)

2371

Payload Capacity (lbs)

1973

Payload Capacity (kgs)

895

GVWR (lbs)

7200

GVWR (kgs)

3265.9

Hitch Weight (lbs)

575

Hitch Weight (kgs)

260.8

Number Of Fresh Water Holding Tanks

1

Total Fresh Water Tank Capacity (gal)

43

Total Fresh Water Tank Capacity (l)

162.8

Number Of Gray Water Holding Tanks

1

Total Gray Water Tank Capacity (gal)

30

Total Gray Water Tank Capacity (l)

113.6

Number Of Black Water Holding Tanks

1

Total Black Water Tank Capacity (gal)

30

Total Black Water Tank Capacity (l)

113.6

Number Of Propane Tanks

2

Total Propane Tank Capacity (gal)

9.4

Total Propane Tank Capacity (lbs)

40

Body Material

Aluminum

Sidewall Construction

Fiberglass

Number of Doors

1

Sliding Glass Door

No

Number of Slideouts

1

Power Retractable Slideout

Yes

Number of Awnings

1

Awning Length (ft)

19

Awning Length (m)

5.8

Power Retractable Awning

Yes

Screened Room

No

Leveling Jack Type

Front Power / Rear Power

Kitchen / Living Area Flooring Type

Carpet / Vinyl

Kitchen Table Configuration

Bench Seats

Kitchen Location

Rear

Living Area Location

Center

Layout

Oven / Stove

Number Of Oven Burners

3

Overhead Fan

Yes

Convection

No

Refrigerator Size

Full-Size

Refrigerator Power Mode

Electric

Number Of Sofas

1

Sofa Material

Vinyl

Reclining Sofa

No

Number Of Recliner / Rockers

2

Material

Vinyl

Max Sleeping Count

6

Number Of Bunk Beds

0

Number Of Double Beds

0

Number Of Full Size Beds

0

Number Of Queen Size Beds

1

Number Of King Size Beds

0

Number Of Convertible / Sofa Beds

2

Master Bedroom Flooring Type

Vinyl

Master Bedroom Door Style

Full Sliding Door

Full Size Master Bedroom Closet

No

Master Bedroom Mirror Doors

No

Master Bedroom Shades / Curtains

Yes

Master Bedroom Location

Front

Bunkhouse

No

Number Of Bathrooms

1

Bathroom Flooring Type

Vinyl

Bathroom Location

Rear

Toilet Type

Plastic

Toilet Location

Rear

Door Type

Plastic / Glass

Shower Location

Rear

Bathroom Sink Location

Rear

Bathroom Medicine Cabinet Location

Rear

Bathroom Mirror Location

Rear

Bathroom Vent / Fan System Location

Rear

Wheels Composition

Aluminum

Number Of Axles

2

Rear Tire Width

205

Rear Tire Aspect Ratio

75

Rear Tire Speed Rating

D

Rear Wheel Diameter

14

Rear Tire (Full Spec)

ST205/75 R14D

Spare Tire Location

Exterior Mounted

Front Brake Type

Not Applicable

Rear Brake Type

Electric Drum

Rear Hitch Type

Receiver

Battery Power Converter

Yes

Air Conditioning Prewiring

Yes

Cable Prewiring

Yes

Phone Prewiring

No

Heat Prewiring

Yes

TV Antenna Prewiring

Yes

Satellite Prewiring

Yes

Washer / Dryer Prewiring

No

Solar

Yes

Back-Up Camera

No

Air Conditioning Type

Automatic

Air Conditioning (BTUs)

13,500

Heater Type

Automatic

Heater (BTUs)

30,000

Water Heater Tank Capacity (g)

0

Water Heater Tank Capacity (l)

0

Water Heater Pump Power Mode

Electrical

Tankless Water Heater

Yes

Number Of Emergency Exits

1

Number Of Radios

1

Satellite

Yes

Speaker Location(s)

Interior / Exterior

Surround Sound

No

Number Of Televisions

1

Primary Color

White

Secondary Color

Not Available

Metallic

No

Paint Swatch File Name

Keystone/White_-_Gray_Exterior_Color.gif

Wallpaper

Yes

Interior Wood Finish

Yes

Bluetooth Audio

Yes

Wi-Fi Capable

Yes

Mobile App Instrumentation

No
