MSRP $388,829. Please Call for Sale Pricing.
Independence RV is pleased to announce the building of a 2023 Newmar Canyon Star 3947 Toy Hauler. This innovative front engine diesel with a garage for your toys and easily accommodates friends & family with power bunks in the garage converting to bench seating for additional dining space. Please reference the Production Build Order for the numerous optional upgrades that have been selected for this Canyon Star Toy Hauler. Give us a call today (877) 281-8452 to learn more about this custom motorhome.
Independence RV is located in Winter Garden, FL – close the world-famous Orlando theme parks and attractions. We are Orlando’s only authorized Newmar dealer, and three-time recipient of the Newmar Diamond award for providing greater than 95% customer satisfaction in sales, service, and delivery.
Photos and descriptive information specific to this Newmar motorhome will be posted when the vehicle is received at Independence RV.
MSRP
$341,166
MSRP + Destination
$341,166
Currency
US Dollars
Basic Warranty
12 Months
Structure Warranty
60 Months
Roof Warranty (Years)
12
Chassis Warranty
60 Months
Chassis Warranty
100,000 Miles
Powertrain Warranty
60 Months
Powertrain Warranty
100,000 Miles
Powertrain Warranty (Kilometers)
160934
Chassis Warranty (Kilometers)
160934
Engine Brand Name
Cummins
Chassis Brand
Freightliner
Engine Type
I6 Diesel Pusher
Chassis Model
XC-Series
Cylinders
6
Horsepower (bhp)
340
Horsepower (kW)
253.7
Horsepower RPM
2600
Torque (Ft Lbs)
700
Torque (Nm)
949.1
Torque RPM
1600
Displacement (l)
6.7
Fuel Type
Diesel
Fuel Requirements
Regular
Carburetion Type
Fuel Injected
Turbocharged
Yes
Supercharged
No
Transmission Brand
Allison
Transmission Type
Automatic
Number Of Speeds
6
Overdrive
Yes
Driveline Type
4X2
Length (ft)
39.92
Length (in)
479
Length (ft/ft)
39
Length (ft/in)
11
Length (m)
12.2
Length (mm)
12200
Width (in)
101.5
Width (mm)
2578.1
Height (in)
155
Height (mm)
3937
Interior Height (in)
84
Interior Height (mm)
2133.6
Wheelbase (in)
274
Wheelbase (mm)
6959.6
Dry Weight (lbs)
25300
Dry Weight (kg)
11476.1
Payload Capacity (lbs)
6700
Payload Capacity (kgs)
3039.1
Towing Capacity (lbs)
6000
Towing Capacity (kgs)
2721.6
GVWR (lbs)
32000
GVWR (kgs)
14515.2
Fuel Capacity (gal)
80
Fuel Capacity (l)
302.8
Number Of Fresh Water Holding Tanks
1
Total Fresh Water Tank Capacity (gal)
75
Total Fresh Water Tank Capacity (l)
283.9
Number Of Gray Water Holding Tanks
1
Total Gray Water Tank Capacity (gal)
60
Total Gray Water Tank Capacity (l)
227.1
Number Of Black Water Holding Tanks
1
Total Black Water Tank Capacity (gal)
40
Total Black Water Tank Capacity (l)
151.4
Number Of Propane Tanks
1
Total Propane Tank Capacity (gal)
25
Total Propane Tank Capacity (lbs)
106
Body Material
Aluminum
Sidewall Construction
Fiberglass
Number of Doors
2
Sliding Glass Door
No
Number of Slideouts
2
Power Retractable Slideout
Yes
Number of Awnings
1
Power Retractable Awning
Yes
Screened Room
No
Leveling Jack Type
Front Power / Rear Power
Kitchen / Living Area Flooring Type
Carpet / Vinyl
Kitchen Table Configuration
Bench Seats
Kitchen Location
Center
Living Area Location
Front
Layout
Oven / Stove
Number Of Oven Burners
3
Overhead Fan
Yes
Convection
Yes
Refrigerator Size
Full-Size
Refrigerator Power Mode
Electric
Number Of Sofas
1
Sofa Material
Leather
Reclining Sofa
No
Number Of Recliner / Rockers
0
Max Sleeping Count
10
Number Of Bunk Beds
0
Number Of Double Beds
0
Number Of Full Size Beds
0
Number Of Queen Size Beds
1
Number Of King Size Beds
0
Number Of Convertible / Sofa Beds
2
Master Bedroom Flooring Type
Carpet / Vinyl
Master Bedroom Door Style
Full Sliding Door
Full Size Master Bedroom Closet
No
Master Bedroom Mirror Doors
No
Master Bedroom Shades / Curtains
Yes
Master Bedroom Location
Center
Bunkhouse
No
Number Of Bathrooms
1
Bathroom Flooring Type
Vinyl
Bathroom Location
Center
Toilet Type
Porcelain
Toilet Location
Center
Door Type
Plastic / Glass
Shower Location
Center
Bathroom Sink Location
Center
Bathroom Medicine Cabinet Location
Center
Bathroom Mirror Location
Center
Bathroom Vent / Fan System Location
Center
Cargo Area Length (in)
120
Cargo Area Length (mm)
3048
Cargo Area Width (in)
95.5
Cargo Area Width (mm)
2425.7
Cargo Area Flooring Type
Rubber
Cargo Area Rear Door Style
Ramp Door
Cargo Area Side Door Style
Conventional
Wheels Composition
Aluminum
Front Wheel Width (in)
8.25
Rear Wheel Width (in)
8.25
Number Of Axles
1
Tire Brand
Michelin
Front Tire Width
275
Front Tire Aspect Ratio
80
Front Wheel Diameter
22.5
Rear Tire Width
275
Rear Tire Aspect Ratio
80
Rear Wheel Diameter
22.5
Front Tire (Full Spec)
Michelin XZE 275/80R 22.5
Rear Tire (Full Spec)
Michelin XZE 275/80R 22.5
Front Brake Type
Hydraulic Disc
Rear Brake Type
Hydraulic Drum
Rear Hitch Type
Receiver
Seat Type
Bucket
Seat Material
Leather
Power Adjustable Seat
Yes
Reclining Seats
Yes
Swivel Seats
Yes
Seat Armrests
Yes
Number Of Seats
2
Number Of Rows
1
Battery Power Converter
Yes
Battery Converter Amps
60
Air Conditioning Prewiring
Yes
Cable Prewiring
Yes
Phone Prewiring
No
Heat Prewiring
Yes
TV Antenna Prewiring
Yes
Satellite Prewiring
Yes
Washer / Dryer Prewiring
Yes
Solar
Yes
Back-Up Camera
Yes
Air Conditioning Type
Automatic
Air Conditioning (BTUs)
27,000
Heater Type
Automatic
Heater (BTUs)
42,000
Water Heater Tank Capacity (g)
0
Water Heater Tank Capacity (l)
0
Water Heater Tank Bypass
Yes
Tankless Water Heater
Yes
Number Of Radios
2
Satellite
Yes
Speaker Location(s)
Interior / Exterior
Surround Sound
Yes
Television Brand Name
Samsung
Number Of Televisions
2
Primary Color
Brown
Secondary Color
Green
Metallic
No
Paint Swatch File Name
Newmar/Bellona_Full_Painted_Exterior_Graphics.gif
Wallpaper
Yes
Interior Wood Finish
Yes
Available In Various Styles
Yes
Bluetooth Audio
Yes
Wi-Fi Capable
Yes
Mobile App Instrumentation
Yes
